Specifications

• Dimensions

  add remove
  • Length:
    91.3 in
  • Overall width:
    36.4 in
  • Overall height:
    45.7 in
  • Seat height, unladen:
    26.2 in
  • Rake (steering head):
    30
  • Wheelbase:
    64.2 in
  • Tires, front specifications:
    100/90B19,57H,BW
  • Tires, rear specifications:
    150/80B16,77H,BW
  • Fuel Capacity:
    5.0 gal
  • Weight, as shipped:
    627 lbs
  • Weight, in running order:
    656 lbs
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117 Classic
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    1923 cc
  • Compression ratio:
    10.3:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    120.2 ft-lb
  • Horsepower:
    98 HP / 73 kW @ 4600 rpm
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    47 mpg (5 l/100 km)
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
  • Clutch:
    Mechanical, 10 plate wet, assist & conventional
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; gaiter covers
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
  • Wheels, front type:
    Chrome aluminum tubeless laced wheel
  • Wheels, rear type:
    Chrome aluminum tubeless laced wheel
  • Brakes, type:
    Solid, uniform expansion rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
