DTCPRIORITY ORDERFAULT CONDITIONSOLUTION
B110347LHCM internal errorSWITCH DIAGNOSTICS
B115346RHCM internal errorSWITCH DIAGNOSTICS
B120037IM internal faultNO INSTRUMENT POWER DIAGNOSTICS
B1210176Fuel level sender shorted low/openFUEL GAUGE AND SENDER DIAGNOSTICS
B1211182Fuel level sender shorted highFUEL GAUGE AND SENDER DIAGNOSTICS
B1212175Fuel signal lowFUEL GAUGE AND SENDER DIAGNOSTICS
B1213176Fuel signal highFUEL GAUGE AND SENDER DIAGNOSTICS
B1300340Radio voltage highAUDIO VOLTAGE DIAGNOSTICS
B1301341Radio voltage lowAUDIO VOLTAGE DIAGNOSTICS
B1302342Faceplate home button stuckFACEPLATE BUTTON DIAGNOSTICS
B1303343Faceplate favorite button stuckFACEPLATE BUTTON DIAGNOSTICS
B1304344Faceplate navigation button stuckFACEPLATE BUTTON DIAGNOSTICS
B1305345Faceplate power/mute button stuckFACEPLATE BUTTON DIAGNOSTICS
B1306399Rear hand controls shorted highREAR AUDIO CONTROL DIAGNOSTICS
81307400Rear hand controls shorted lowREAR AUDIO CONTROL DIAGNOSTICS
81308401Rear volume up button stuckREAR AUDIO CONTROL DIAGNOSTICS
B1309402Rear volume down button stuckREAR AUDIO CONTROL DIAGNOSTICS
B1310403Rear mode button stuckREAR AUDIO CONTROL DIAGNOSTICS
81311404Rear PTT button stuckREAR AUDIO CONTROL DIAGNOSTICS
B1312405Rear tune up button stuckREAR AUDIO CONTROL DIAGNOSTICS
B1313406Rear tune down button stuckREAR AUDIO CONTROL DIAGNOSTICS
B1314346LHCM VR PTT button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1315347LHCM up button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1316348LHCM left button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1317349LHCM center button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1318350LHCM right button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1319351LHCM down button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1320352RHCM info button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1321353RHCM up button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1322354RHCM left button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1323355RHCM center button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1324356RHCM right button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1325357RHCM down button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1326358RHCM CB squelch up button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1327359RHCM CB PTT button stuckFRONT HAND CONTROLS DIAGNOSTICS
B1328360RHCM CB squelch down button stuckFRONT HAND CONTROLS DIAGNOSTICS
81329361Faceplate preset button 1 stuckFACEPLATE BUTTON DIAGNOSTICS
B1330362Faceplate preset button 2 stuckFACEPLATE BUTTON DIAGNOSTICS
B1331363Faceplate preset button 3 stuckFACEPLATE BUTTON DIAGNOSTICS
B1332364Faceplate preset button 4 stuckFACEPLATE BUTTON DIAGNOSTICS
81333365Faceplate preset button 5 stuckFACEPLATE BUTTON DIAGNOSTICS
B1334366Faceplate preset button 6 stuckFACEPLATE BUTTON DIAGNOSTICS
B1335367Faceplate preset button 7 stuckFACEPLATE BUTTON DIAGNOSTICS
B1336368Faceplate preset button 8 stuckFACEPLATE BUTTON DIAGNOSTICS
B1337369Front left speaker shorted togetherFRONT SPEAKER DIAGNOSTICS
B1338370Front left speaker openFRONT SPEAKER DIAGNOSTICS
B1339371Front left speaker shorted lowFRONT SPEAKER DIAGNOSTICS
B1340372Front left speaker shorted highFRONT SPEAKER DIAGNOSTICS
B1341373Rear left speaker shorted togetherREAR SPEAKER DIAGNOSTICS
B1342374Rear left speaker openREAR SPEAKER DIAGNOSTICS
B1343375Rear left speaker shorted lowREAR SPEAKER DIAGNOSTICS
B1344376Rear left speaker shorted highREAR SPEAKER DIAGNOSTICS
B1345377Front right speaker shorted togetherFRONT SPEAKER DIAGNOSTICS
B1346378Front right speaker openFRONT SPEAKER DIAGNOSTICS
B1347379Front right speaker shorted lowFRONT SPEAKER DIAGNOSTICS
B1348380Front right speaker shorted highFRONT SPEAKER DIAGNOSTICS
B1349381Rear right speaker shorted togetherREAR SPEAKER DIAGNOSTICS
B1350382Rear right speaker openREAR SPEAKER DIAGNOSTICS
B1351383Rear right speaker shorted lowREAR SPEAKER DIAGNOSTICS
81352384Rear right speaker shorted highREAR SPEAKER DIAGNOSTICS
B1353385Speaker outputDC offset DTC B1353
B1354386GPS antenna openSECURITY ANTENNA DIAGNOSTICS
B1355387GPS antenna shorted lowSECURITY ANTENNA DIAGNOSTICS
B1356388SDARS antenna openSECURITY ANTENNA DIAGNOSTICS
B1357389SDARS antenna shortedSECURITY ANTENNA DIAGNOSTICS
B1358390Front left headset shorted highHEADSET DTCS
B1359391Front right headset shorted highHEADSET DTCS
B1360392Front left headset shorted lowHEADSET DTCS
B1361393Front right headset shorted lowHEADSET DTCS
B1362394Rear left headset shorted highHEADSET DTCS
B1363395Rear right headset shorted highHEADSET DTCS
B1364396Rear left headset shorted lowHEADSET DTCS
81365397Rear right headset shorted lowHEADSET DTCS
B1366398Internal thermal shutdown errorDTC 81366
B1367451WIM fault detectedCode used to support P&A parts.
B1401407Amp voltage lowAUDIO VOLTAGE DIAGNOSTICS
B1402408Amp voltage highAUDIO VOLTAGE DIAGNOSTICS
81403409Speaker output DC offsetAMPLIFIER 1 DTCS
B1404410Internal thermal shutdown errorAMPLIFIER 1 DTCS
B1405427EQ correlation errorAUDIO SYSTEM SYMPTOMS
81406428Invalid or missing EQAUDIO SYSTEM SYMPTOMS
B1410411Channel 1 speaker openAMPLIFIER 1 DTCS
B1411412Channel 1 speaker shorted lowAMPLIFIER 1 DTCS
B1412413Channel 1 speaker shorted highAMPLIFIER 1 DTCS
B1413414Channel 1 speaker shorted togetherAMPLIFIER 1 DTCS
B1420415Channel 2 speaker openAMPLIFIER 1 DTCS
B1421416Channel 2 speaker shorted lowAMPLIFIER 1 DTCS
B1422417Channel 2 speaker shorted highAMPLIFIER 1 DTCS
B1423418Channel 2 speaker shorted togetherAMPLIFIER 1 DTCS
B1430419Channel 3 speaker openAMPLIFIER 1 DTCS
B1431420Channel 3 speaker shorted lowAMPLIFIER 1 DTCS
B1432421Channel 3 speaker shorted highAMPLIFIER 1 DTCS
81433422Channel 3 speaker shorted togetherAMPLIFIER 1 DTCS
B1440423Channel 4 speaker openAMPLIFIER 1 DTCS
B1441424Channel 4 speaker shorted lowAMPLIFIER 1 DTCS
B1442425Channel 4 speaker shorted highAMPLIFIER 1 DTCS
B1443426Channel 4 speaker shorted togetherAMPLIFIER 1 DTCS
B21024System power output shorted highSYSTEM POWER CIRCUIT DIAGNOSTICS
B21035System power output shorted lowSYSTEM POWER CIRCUIT DIAGNOSTICS
B21046System power output over- loadedSYSTEM POWER CIRCUIT DIAGNOSTICS
B2106257L4 open outputHEADLAMP DIAGNOSTICS
B2107225L4 output shorted highHEADLAMP DIAGNOSTICS
B2108226L4 output shorted lowHEADLAMP DIAGNOSTICS
B2109227L4 output overloadedHEADLAMP DIAGNOSTICS
B2112132ACC output shorted highACC CIRCUIT DIAGNOSTICS
B2113134ACC output shorted lowACC CIRCUIT DIAGNOSTICS
B2114136ACC output overloadedACC CIRCUIT DIAGNOSTICS
B211692Fuel pump output openFUEL PUMP DIAGNOSTICS
B211793Fuel pump output shorted highFUEL PUMP DIAGNOSTICS
B211894Fuel pump output shorted lowFUEL PUMP DIAGNOSTICS
B211995Fuel pump output overloadedFUEL PUMP DIAGNOSTICS
B212158Starter output openSTARTER OUTPUT DTCS
B212259Starter output shorted highSTARTER OUTPUT DTCS
B212360Starter output shorted lowSTARTER OUTPUT DTCS
B212461Starter output overloadedSTARTER OUTPUT DTCS
B2127243E4 output shorted highHORN DIAGNOSTICS
B2128244E4 output shorted lowHORN DIAGNOSTICS
B2129245E4 output overloadedHORN DIAGNOSTICS
B2131233High beam open outputHEADLAMP DIAGNOSTICS
B2132234High beam output shorted highHEADLAMP DIAGNOSTICS
B2133235High beam output shorted lowHEADLAMP DIAGNOSTICS
B2134236High beam output overloadedHEADLAMP DIAGNOSTICS
B2136229Low beam open outputHEADLAMP DIAGNOSTICS
B2137230Low beam output shorted highHEADLAMP DIAGNOSTICS
B2138231Low beam output shorted lowHEADLAMP DIAGNOSTICS
B2139232Low beam output overloadedHEADLAMP DIAGNOSTICS
B2141207Left front turn signal output openFRONT TURN SIGNAL DIAGNOSTICS
B2143214Left front turn signal output shorted lowFRONT TURN SIGNAL DIAGNOST ICS
B2144215Left front turn signal output overloadedFRONT TURN SIGNAL DIAGNOST ICS
B2146216Right front turn signal output openFRONT TURN SIGNAL DIAGNOSTICS
B2148217Right front turn signal output shorted lowFRONT TURN SIGNAL DIAGNOST ICS
B2149218Right front turn signal output overloadedFRONT TURN SIGNAL DIAGNOST ICS
82151219Left rear turn signal output openREAR TURN SIGNAL DIAGNOSTICS
82153220Left rear turn signal output shorted lowREAR TURN SIGNAL DIAGNOST ICS
B2154221Left rear turn signal output overloadedREAR TURN SIGNAL DIAGNOSTICS
B2156222Right rear turn signal output openREAR TURN SIGNAL DIAGNOSTICS
B2158223Right rear turn signal output shorted lowREAR TURN SIGNAL DIAGNOST ICS
B2159224Right rear turn signal output overloaderREAR TURN SIGNAL DIAGNOST ICS
B2161198Brake lamp output openSTOP LAMP DIAGNOSTICS
B2163199Brake lamp output shorted lowSTOP LAMP DIAGNOSTICS
B2164200Brake lamp output overloadedSTOP LAMP DIAGNOSTICS
B2168172Running lights output shorted lowRUNNING LAMP DIAGNOSTICS
B2169173Running lights output over-loadedRUNNING LAMP DIAGNOSTICS
B2172237H2 output shorted highALARM DIAGNOSTICS
B2173238H2 output shorted lowALARM DIAGNOSTICS
82176239Security antenna output openSECURITY ANTENNA DIAGNOSTICS
B2177240Security antenna output shorted highSECURITY ANTENNA DIAGNOSTICS
B2178241Security antenna output shorted lowSECURITY ANTENNA DIAGNOSTICS
B2183249G2 output shorted lowADDITIONAL OUTPUT DIAGNOSTICS
B2188254G3 output shorted lowADDITIONAL OUTPUT DIAGNOSTICS
B2193257H4 output shorted lowADDITIONAL OUTPUT DIAGNOSTICS
B2198259H3 output shorted lowADDITIONAL OUTPUT DIAGNOSTICS
B220152IGN switch off w/VSSIGN SWITCH DIAGNOSTICS
B220253Ignition switch accy with vehicle speedIGN SWITCH DIAGNOSTICS
B220350Ignition switch input shorted lowIGN SWITCH DIAGNOSTICS
B220651Run/stop switch input open/shorted highENGINE STOP SWITCH DIAGNOSTICS
B220854Run/stop switch input shorted lowENGINE STOP SWITCH DIAGNOSTICS
B221055Run/stop switch inputs open bothSWITCH DIAGNOSTICS
B221256Run/stop switch inputs both closedSWITCH DIAGNOSTICS
82218131Neutral switch shorted lowNEUTRAL SWITCH DIAGNOSTICS
B2223197Rear brake switch shorted low (light on)STOP LAMP DIAGNOSTICS
B2226247BAS input openBCM not configured properly.
B2228250BAS input shorted lowBCM not configured properly.
B2231312Fork locked w/VSSBCM not configured properly. This DTC should only apply to CVO models.
B2232313Fork lock shorted highBCM not configured properly. This DTC should only apply to CVO models.
B2233314Fork lock shorted lowBCM not configured properly. This DTC should only apply to CVO models.
B2234315Fork lock detected w/option disabledBCM not configured properly. This DTC should only apply to CVO models.
B2235316Fork lock configuration invalidBCM not configured properly. This DTC should only apply to CVO models.
B2250128Clutch switch stuckSWITCH DIAGNOSTICS
B2251242Horn switch stuckSWITCH DIAGNOSTICS
B2252437High beam switch stuckSWITCH DIAGNOSTICS
B2253228FTP switch stuckSWITCH DIAGNOSTICS
B2254203Left turn switch stuckSWITCH DIAGNOSTICS
B2255246Trip switch stuckTrip Odometer Functions Inoperative, DTC 82255
B2256208LHCM police siren power switch stuckBCM not configured properly. This DTC should only apply to Police models.
B2257209LHCM police siren wail power switch stuckBCM not configured properly. This DTC should only apply to Police models.
B2258210LHCM police siren yelp switch stuckBCM not configured properly. This DTC should only apply to Police models.
B226057Start switch stuckSWITCH DIAGNOSTICS
B2261204Right switch stuck turnSWITCH DIAGNOSTICS
B2262196Front switch stuck brakeSWITCH DIAGNOSTICS
B2263202Hazard switch stuckSWITCH DIAGNOSTICS
B2264211RHCM police lights power switch stuckBCM not configured properly. This DTC should only apply to Police models.
B2265212RHCM police lights front switch stuckBCM not configured properly. This DTC should only apply to Police models.
B2266213RHCM police lights rear switch stuckBCM not configured properly. This DTCshould only apply to Police models.
B227027BCM internal errorSWITCH DIAGNOSTICS
B227126BCM voltage lowBCM VOLTAGE DIAGNOSTICS
B227233BCM/IM voltage highBCM VOLTAGE DIAGNOSTICS
B227449Constant battery line errorOdometer Self-Diagnostic Inoperative: DTC 00001, 00002, U0011, B2274
C056238ABS voltage lowABS VOLTAGE DIAGNOSTICS
C056340ABS voltage highABS VOLTAGE DIAGNOSTICS
C1014183ABS ECU relay errorINTERNAL FAULT DIAGNOSTICS
C1021191ABS front WSS always zeroWSS DIAGNOSTICS
C1023192ABS rear WSS always zeroWSS DIAGNOSTICS
C1025194ABS front wheel speed intermittentWSS DIAGNOSTICS
C1027195ABS rear wheel speed intermittentWSS DIAGNOSTICS
C1029193ABS wheel speed difference too highWSS DIAGNOSTICS
C1032189ABS front wheel speed circuit open shortedWSS DIAGNOSTICS
C1034190ABS rear wheel speed circuit open shortedWSS DIAGNOSTICS
C1040184ABS pump/motor errorINTERNAL FAULT DIAGNOSTICS
C105539ABS ECU internal errorINTERNAL FAULT DIAGNOSTICS
C1061185ABS front apply solenoid circuit open/high resistanceINTERNAL FAULT DIAGNOSTICS
C1062187ABS front release solenoid circuit open/high resistanceINTERNAL FAULT DIAGNOSTICS
C1065186ABS rear apply solenoid circuit open/high resistanceINTERNAL FAULT DIAGNOSTICS
C1066188ABS rear release solenoid circuit open/high resistanceINTERNAL FAULT DIAGNOSTICS
C1071283Rear prime valve errorINTERNAL FAULT DIAGNOSTICS
C1072284Rear isolation valve errorINTERNAL FAULT DIAGNOSTICS
C1073285Front isolation valve errorINTERNAL FAULT DIAGNOSTICS
C1074286Front prime valve errorINTERNAL FAULT DIAGNOSTICS
C1075287Front linked inlet valve errorINTERNAL FAULT DIAGNOSTICS
C1076288Front linked outlet valve errorINTERNAL FAULT DIAGNOSTICS
C1077289Front circuit pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1078290Rear circuit pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1081291Front master pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1082292Front master pressure sensor offset errorINTERNAL FAULT DIAGNOSTICS
C1083293Front wheel pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1084294Front wheel pressure sensor offset errorINTERNAL FAULT DIAGNOSTICS
C1085295Rear master pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1086296Rear master pressure sensor offset errorINTERNAL FAULT DIAGNOSTICS
C1087297Rear wheel pressure sensor errorINTERNAL FAULT DIAGNOSTICS
C1088298Rear wheel pressure sensor offset errorINTERNAL FAULT DIAGNOSTICS
C1089299Pressure sensor external supply errorINTERNAL FAULT DIAGNOSTICS
C115943ABS invalid storedVIN INVALID VIN DIAGNOSTICS
C117841ABS no VIN received fromECM INVALID VIN DIAGNOSTICS
C118442ABS invalid VIN fromECM INVALID VIN DIAGNOSTICS
C1195266Wake up errorINTERNAL FAULT DIAGNOSTICS
P0031153Front HO2S open lowHO2S DIAGNOSTICS
P0032156Front HO2S shorted highHO2S DIAGNOSTICS
P0051154Rear HO2S open lowHO2S DIAGNOSTICS
P0052155Rear HO2S shorted highHO2S DIAGNOSTICS
P0072112AAT sensor lowAAT SENSOR DIAGNOSTICS
P0073113AAT sensor high openMT SENSOR DIAGNOSTICS
P0107100MAP sensor failed low openTMAP SENSOR DIAGNOSTICS
P0108101MAP sensor failed high/open portTMAP SENSOR DIAGNOSTICS
P0112123IAT sensor shorted lowTMAP SENSOR DIAGNOSTICS
P0113125IAT sensor high openTMAP SENSOR DIAGNOSTICS
P0117102ET sensor shorted lowET SENSOR DIAGNOSTICS
P0118107ET sensor high openET SENSOR DIAGNOSTICS
P012076TPS 1 range errorTCA DIAGNOSTICS
P012274TPS 1 lowTCA DIAGNOSTICS
P012375TPS 1 high openTCA DIAGNOSTICS
P013115702 sensor low/engine lean (front)HO2S DIAGNOSTICS
P0132159Engine running rich (front)HO2S DIAGNOSTICS
P0134161Oxygen sensor high/open (front)HO2S DIAGNOSTICS
P015115802 sensor low/engine lean (rear)HO2S DIAGNOSTICS
P0152160Engine running rich (rear)HO2S DIAGNOSTICS
P015416202 sensor high/open (rear)HO2S DIAGNOSTICS
P022079TPS 2 range errorTCA DIAGNOSTICS
P022277TPS 2 open lowTCA DIAGNOSTICS
P022378TPS 2 highTCA DIAGNOSTICS
P026196Fuel injector low/open (front)FUEL INJECTOR DIAGNOSTICS
P026297Fuel injector shorted high (front)FUEL INJECTOR DIAGNOSTICS
P026498Fuel injector low/open (rear)FUEL INJECTOR DIAGNOSTICS
P026599Fuel injector shorted high (rear)FUEL INJECTOR DIAGNOSTICS
P0325139Knock sensor front open circuitKNOCK SENSOR DIAGNOSTICS
P0327140Knock sensor front circuit lowKNOCK SENSOR DIAGNOSTICS
P0328141Knock sensor front circuit highKNOCK SENSOR DIAGNOSTICS
P0330142Knock sensor rear open circuitKNOCK SENSOR DIAGNOSTICS
P0332143Knock sensor rear circuit lowKNOCK SENSOR DIAGNOSTICS
P0333144Knock sensor rear circuit highKNOCK SENSOR DIAGNOSTICS
P037165CKP sensor wrong number of pulsesCKP SENSOR DIAGNOSTICS
P037464CKP sensor no pulsesCKP SENSOR DIAGNOSTICS
P0444147Purge solenoid low openPURGE SOLENOID DIAGNOSTICS
P0445148Purge solenoid shorted highPURGE SOLENOID DIAGNOSTICS
P0462174Fuel sender shorted lowFUEL GAUGE AND SENDER DIAGNOSTICS
P0463175Fuel sender shorted high/openFUEL GAUGE AND SENDER DIAGNOSTICS
P0502137VSS failed lowPURGE SOLENOID DIAGNOSTICS
P0503138VSSfailed high VSS DIAGNOSTICS
P0505148Idle speed control - unstableIDLE SPEED CONTROL DIAGNOSTICS
P0522168Engine oil pressure sensor/switch shorted lowINDICATOR LAMPS
P0523169Engine oil pressure sensor/switch shorted high openINDICATOR LAMPS
P0562127ECM voltage low BATTERYAND SYSTEM VOLTAGE DIAGNOSTICS
P0572202Brake switch lowBRAKE SWITCH DIAGNOSTICS
P0577163Cruise controlinput error Cruise Control
P060329ECM EEPROM memory errorECM INTERNAL DIAGNOSTICS
P060528ECM FLASH memory errorECM INTERNAL DIAGNOSTICS
P0641625 Volt reference out of range5V REFERENCE DIAGNOSTICS
P0651635 Volt reference 2 out of range5V REFERENCE DIAGNOSTICS
P0693119Chassis fan control circuit shorted lowCHASSIS FAN DIAGNOSTICS
P0694120Chassis fan control circuit shorted highCHASSIS FAN DIAGNOSTICS
P100932VTD disabled fuel due to bad passwordDTC P1009
P1017103ET indicates overheatingDTC P1017
P1019106ECT difference (high temp)ECT SENSOR DIAGNOSTICS
P127067TGS 2 ND validation errorDTC P1270
P1501166JSS lowJSS DIAGNOSTICS
P1502167JSS high openJSS DIAGNOSTICS
P1505445Power limit violationHESITATION OR LOSS OF POWER
P1510447ETC limited performance modeETC MANAGEMENT DIAGNOSTICS
P1511448ETC power management modeETC MANAGEMENT DIAGNOSTICS
P1512449ETC forced idle modeETC MANAGEMENT DIAGNOSTICS
P151487ETC airflow errorETC ERROR DIAGNOSTICS
P160066ETC watchdog errorETC ERROR DIAGNOSTICS
P1655164ACR solenoid open lowACR Diagnostics
P1656165ACR solenoid shorted highACR Diagnostics
P1691115Cooling fan left low openCOOLING FAN DIAGNOSTICS
P1692116Cooling fan left shorted highCOOLING FAN DIAGNOSTICS
P1693117Cooling fan right low openCOOLING FAN DIAGNOSTICS
P1694118Cooling fan right shorted highCOOLING FAN DIAGNOSTICS
P210082ETC driver open circuitETC ACTUATOR DIAGNOSTICS
P210183ETC actuation errorETC ACTUATOR DIAGNOSTICS
P210284ETC driver shorted lowETC ACTUATOR DIAGNOSTICS
P210385ETC driver shorted highETC ACTUATOR DIAGNOSTICS
P2105446ETC forced shutdown modeDTC P2105, P2107
P210768ETC driver internal errorDTC P2105, P2107
P211981ETC actuator return errorDTC P2119
P212269TGS 1 low/openTGS DIAGNOSTICS
P212370TGS 1 highTGS DIAGNOSTICS
P212771TGS 2 low/openTGS DIAGNOSTICS
P212872TGS 2 highTGS DIAGNOSTICS
P213580TPS correlation errorCORRELATION ERROR DIAGNOSTICS
P213873TGS correlation errorCORRELATION ERROR DIAGNOSTICS
P217686ETC zero position learning errorDTC P2176
P2184121ECT sensor lowECT SENSOR DIAGNOSTICS
P2185122ECT sensor highECT SENSOR DIAGNOSTICS
P230088Ignition coil driver low/open (front)IGN COIL DRIVER DIAGNOSTICS
P230189Ignition coil driver shorted high (front)IGN COIL DRIVER DIAGNOSTICS
P230390Ignition coil driver low/open (rear)IGN COIL DRIVER DIAGNOSTICS
P230491Ignition coil driver shorted high (rear)IGN COIL DRIVER DIAGNOSTICS
P2602104Coolant pump "A" control circuit lowCOOLING PUMP DIAGNOSTICS
P2603105Coolant pump "A" control circuit highCOOLING PUMP DIAGNOSTICS
U00011CAN BUS errorOdometer Self-Diagnostic Inoperative: DTC 00001, 00002, U0011, B2274
U000216CAN comm bus perf errorOdometer Self Diagnostic Inoperative: DTC 00001, 00002, U0011, 82274
U000313Network management monitoringNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U00112CAN bus low shorted to CAN bus highOdometer Self-Diagnostic Inoperative: DTC 00001, 00002, 00011, B2274
U01007Lost comm w/ECMNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U012111Lost comm w/ABSNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U01403Lost comm w/BCMNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U01419Lost comm w/LHCMNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U01428Lost comm w/RHCMNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U015610Lost comm w/speedoNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U0158180Lost comm w/fuel gaugeSECONDARY COMMUNICATION DIAGNOSTICS
U0159181Lost comm w/volt gaugeSECONDARY COMMUNICATION DIAGNOSTICS
U0160179Lost comm w/fuel and volt gaugesSECONDARY COMMUNICATION DIAGNOSTICS
U0184323Lost comm w/radioNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U0185325Lost comm w/AMP1 AMP COMMUNICATION DIAGNOSTICS
U0186326Lost comm w/AMP2 AMP COMMUNICATION DIAGNOSTICS
U018720Lost comm w/AMP3 AMP COMMUNICATION DIAGNOSTICS
U018821Lost comm w/AMP4 AMP COMMUNICATION DIAGNOSTICS
U030015Internal control module software incompatibilityNO VEHICLE POWER OR LOST COMMUNICATION DTCS
U1302324ACC bus pert errorSECONDARY COMMUNICATION DIAGNOSTICS
U1401331Lost comm w CBSECONDARY COMMUNICATION DIAGNOSTICS
U1401331Lost comm w CBCOMMUNICATION DIAGNOSTICS
U1405450ACC bus lost comm w/ WIMCode used to support P&A parts

Retrieving Trouble Codes on Your Harley-Davidson Motorcycle

Odometer Self-Diagnostics

Diagnostic Mode

To enter diagnostic mode, press and hold the trip odometer trigger switch located on the left handlebar controls, while turning the IGN ON.

Note

The trip odometer trigger switch is located in the left-hand control module. The switch signal is sent to the speedometer over the CAN bus. If there is a problem with the CAN bus, the odometer self-diagnostic mode may not function.

  1. Release the trip odometer trigger switch. "diag" will appear on the odometer display.
  2. Press and release the trip odometer trigger switch. ECM will appear on the odometer display. It will have either a "Y" or an "N" after it, depending if there are any ECM codes or not.
  3. Quickly press and release the trip odometer trigger switch to cycle through the modules. Modules include the BCM, SPDO, ABS, and RAD.
  4. Once the desired module is displayed, press and hold the trip odometer trigger switch.
  5. If any DTCs are stored in the module, the odometer will display the DTC. Quickly pressing and releasing the trip odometer trigger switch will cycle through stored DTCs.
  6. When all DTCs have been cycled the odometer will display "end".
  7. To clear all DTCs in that module press and hold the trip odometer trigger switch, while a DTC is displayed. If DTCs are not to be cleared, quickly press and release the trip odometer trigger switch. The part number of the module will be displayed.
  8. Press and release the trip odometer trigger switch again to continue to the next module.
  9. Make note of all DTCs. Clear all DTCs and operate the vehicle to verify that DTCs set and are current. Historic DTCs are not to be diagnosed unless the condition is reoccurring and intermittent.
  10. Turn IGN OFF to exit diagnostic mode. If IGN is not turned off, the vehicle will exit diagnostics mode when the vehicle starts moving.

Harley Trouble Code Types

There are three types of DTCs: current, pending, and historic. The odometer self-diagnostics displays all codes and differentiates between current and historic with a letter designator.

  • Odometer self-diagnostics will display both current and historic DTCs.
  • Current DTCs reside in the memory of the ECM, BCM, instruments, radio, or ABS module (if equipped) until the DTC is resolved.
  • A historic DTC can be cleared by use of odometer self-diagnostics or after a total of 40 error-free ignition cycles (start and run cycle) have elapsed.

Current DTCs are those that presently disrupt motorcycle operations and are set during the current ignition cycle. To determine whether current DTCs are present, clear the DTCs and operate the vehicle within the parameters for setting the DTC. See the appropriate diagnostic procedures for solutions.

Some DTCs require multiple occurrences or drive cycles to set. When these DTCs are first recognized but have not been repeated enough to be set as current DTCs, they are reported as pending DTCs.

If a particular problem happens to resolve itself, the active status problem is dropped and it becomes a historic DTC rather than a current DTC. DTCs will also lose their current status when the ignition is turned off. If the problem still exists when the ignition is turned on, the code will show as current.

Historic DTCs are stored for 40 ignition cycles to assist in the diagnosis of intermittent faults. On the 40th error-free cycle, the DTC will clear itself.

It is important to note that historic DTCs will exist whenever the system indicates the existence of a current fault. See Multiple Trouble Codes. if multiple DTCs are found.

Diagnostic procedures are designed for use with current DTCs. As a result, they frequently suggest part replacement. When diagnosing a historic DTC, the procedures can be helpful but should not lead to part replacement without verification that the part is faulty.

Emissions-related DTCs will illuminate the check engine lamp for three warm-up cycles after the DTC has transitioned from current to historic.

Multiple Trouble Codes

All DTCs are assigned a priority number to determine the order in which they should be diagnosed. If there are multiple DTCs present, always diagnose the highest priority first.

  • Complete the repair.
  • Restore connections.
  • Clear DTCs.
  • Start vehicle. Perform several cycles to verify a code did not return.
  • Perform odometer self-diagnostics test to verify repair and DTCs have been cleared. If any DTCs are still present, refer to Diagnostics (Pages 1-2).

Clearing DTCs

Clear DTCs after any diagnostic or repair procedure. The odometer is capable of displaying and clearing ECM, BCM, instruments, radio, and ABS DTCs. Once DTCs are cleared perform a road test to verify DTCs do not return. It is important to perform a road test and not simply start the motorcycle since some DTCs may require vehicle speed or other inputs to validate repair.

Security Lamp

See Figure 1-1. The security lamp turns on when:

  • Current DTCs are present in the BCM.
  • Non-emission-related DTCs are present in the ECM.

Wilkins Harley-Davidson servers Vermont and New Hampshire riders with all your Harley-Davidson service, parts, and motorcycle needs.

CONTACT US

Filter by
Inventory status
Clear
Showing 1 - 12 of 189 results
